Tutorial

Learn how to use the Android Native Developer's Kit

Before you start

Download View Info GeoIMEI 1. 0 The International Mobile Equipment Identity or IMEI is a number unique to every mobile phone, as well as some satellite phones. It is usually found printed inside the battery compartment of the phone. Advanced Uninstaller PRO will then uninstall Android Language Project. After removing Android Language Project, Advanced Uninstaller PRO will offer to run an additional cleanup. Press Next to perform the cleanup. All the items of Android Language Project which have been left behind will be detected and you will be able to delete them.

One of the motivations for exploring the NDK in the first place is the opportunity to leverage open source projects, many of which are written in C. After completing this tutorial, you will have learned how to create a Java Native Interface (JNI) library, written in C and compiled with the Native Development Kit (NDK), and incorporate the library into an Android application written in the Java language. The application demonstrates how to perform basic image processing operations against raw image data. You will also learn how to extend the Eclipse build environment to integrate an NDK project into an Android SDK project file. From this foundation, you will be better equipped to port existing open source code to the Android platform.

About this tutorial

This tutorial introduces the Android NDK within the Eclipse environment. The NDK is used to add functionality to an Android application using the C programming language. The tutorial begins with a high-level look at the NDK and its common usage scenarios. From there, the topic of image processing is introduced, followed by an introduction and demonstration of this tutorial’s application: IBM Photo Phun. This application is a mix of SDK-based Java code and NDK-compiled C code. The tutorial moves on to introduce the Java Native Interface (JNI), which is the technology of interest when working with the NDK. A look ahead to the completed project’s source files provides a roadmap for the application constructed here. Then, in a step-by-step manner, you will construct this application. The Java class and C source files are explained. To conclude, the Eclipse build environment is customized to integrate the NDK tool chain directly into the easy-to-use Eclipse build process.

Prerequisites

To follow this tutorial, you should be comfortable constructing Android applications with the Android SDK and have a basic familiarity with the C programming language. In addition, you will need the following:

• Eclipse and Android Developer Tools (ADT) — Primary code editor, Java Compiler, and Android Development Tools Plug-in
• Android Software Developer Kit (SDK)
• Android Native Developer Kit (NDK)
• PNG Image — Image used for testing image processing operations

I created the code samples for this tutorial on a MacBook Pro with Eclipse V3.4.2 and Android SDK V8, which supports the Android release labeled 2.2 (Froyo). The NDK release used in this tutorial is r4b. The code requires version r4b or later because the image handling capabilities of the Android NDK are not available in prior releases of the NDK.

See Related links for links to these tools.

The Android NDK

Let’s begin with a look at the Android NDK and how it can be used for enhancing the Android platform. While the Android SDK provides a very rich programming environment, the Android NDK broadens the horizons and can speed up the delivery of desired functionality by bringing in existing source code, some of which may be proprietary and some of which may be open source code.

The NDK

The NDK is a software release available as a free download from the Android website. The NDK includes all the components necessary to incorporate functionality written in C into an Android application. The initial release of the NDK offered only the most primitive of functionality with significant constraints. With each successive release, the NDK has expanded its capabilities. As of r5 of the NDK application, authors can write a significant portion of an application directly in C, including user interface and event-handling capability. The features enabling the image handling functionality demonstrated here were introduced with the r4b version of the NDK.

Picktorrent: mitcalc authorization code - Free Search and Download Torrents at search engine. Download Music, TV Shows, Movies, Anime, Software and more. There are also crack groups who work together in order to crack software, games, etc. If you search for 'mitcalc authorization code crack', you will often see the word crack amongst the results, which implies it is the full version of the product. Mitcalc. Authorization Code For Mitcalc Serial Numbers. Convert Authorization Code For Mitcalc trail version to full software. Many downloads like Mitcalc Authorization Code may also include a serial number, cd key or keygen. If this is the case then it's usually included in the full crack download archive itself. If you are still having trouble finding Mitcalc Authorization Code after simplifying your search term then we highly recommend using the alternative full. Mitcalc Authorization Code Crack torrent. Found results for Mitcalc Authorization Code crack, serial & keygen. Our results are updated in real-time and rated by our users. Mitcalc Authorization Code was added to DownloadKeeper this week and last updated on 14-Oct-2015. New downloads are added to the member section daily and we now have.

Two common uses of the NDK are to increase application performance and to leverage existing C code by porting it to Android. Let’s look first at performance improvement. Writing code in C does not guarantee a significant increase in performance. In fact, poorly written native code can actually slow down an application when compared to a well-written Java application. Application performance improvements are available when carefully crafted functions written in C are leveraged to perform memory-based or computationally intensive operations like those demonstrated in this tutorial. In particular, algorithms that leverage pointer arithmetic are particularly ripe for use with the NDK. The second common use case for the NDK is to port an existing body of C code written for another platform, such as Linux®. This tutorial demonstrates the NDK in a manner that highlights the performance and the re-use cases.

The NDK contains a compiler and build scripts, allowing you to focus on the C source files and leave the build magic to the NDK installation. The NDK build process is easily incorporated into the Eclipse development environment, which is demonstrated in the section on Customizing Eclipse.

Before jumping into the application itself, let’s take a brief detour to discuss some fundamentals of digital image processing.

Fundamentals of digital imaging processing

An enjoyable aspect of modern computer technology is the advent and ubiquity of digital photography. There is more to digital photography than simply catching your kid doing something cute. Digital images are found everywhere from candid cellphone shots to high-end wedding albums, deep-space images, and numerous other applications. Digital images are easy to capture, exchange, and even alter. Modifying a digital image is of interest to us here and represents the core functionality of the tutorial’s sample application.

Digital image manipulation occurs in myriad ways, including but not limited to the following operations:

• Cropping — Extracting a portion of an image
• Scaling — Changing the size of an image
• Rotating — Changing the orientation of an image
• Conversion — Converting from one format to another
• Sampling — Changing the density of an image
• Mixing/Morphing — Changing the appearance of an image
• Filtering — Extracting elements of an image, such as colors or frequencies
• Edge detection — Used for machine vision applications to identify objects within an image
• Compressing — Reducing the storage size of an image

• Enhancing an image through pixel operations:

  • Histogram equalization
  • Contrast
  • Brightness

Some of these operations are performed on a pixel-by-pixel basis, while others involve matrix math to work on small sections of the image at a time. Regardless of the operations, all image processing algorithms involve working with raw image data. This tutorial demonstrates the use of pixel and matrix operations in the C programming language, running on an Android device.

The application architecture

Android Get Imei

This section explores the architecture of the tutorial’s sample application, beginning with a high-level glance at the completed project, then progressing through each of the major steps in its construction. You can follow along step by step to reconstruct the application yourself or you can download the complete project from the Related links.

The completed project

This tutorial demonstrates the construction of a simple image processing application, IBM Photo Phun. Figure 1 shows a screenshot from the Eclipse IDE with the project expanded to see the source and output files.

Figure 1. Eclipse project view

The application’s UI is constructed with traditional Android development techniques, using a single layout file (main.xml) and a single Activity, implemented in IBMPhotoPhun.java. A single C source file, located in a folder named jni, beneath the project’s main folder, contains the image processing routines. The NDK tool chain compiles the C source file into a shared library file named libibmphotophun.so. The compiled library file(s) are stored in the libs folder. A library file is created for each target hardware platform or processor architecture. Table 1 enumerates the application’s source files.

Table 1. The required application source files

If you don’t have a working Android development environment, now is a great time to install the Android tools. For more information on how to set up an Android development environment, see Related links for links to the required tools, plus some introductory articles and tutorials on developing applications for Android. Having a familiarity with Android is helpful in understanding this tutorial.

Now that you have an overview of the architecture and the application, you can see how it looks when running on an Android device.

Demonstrating the application

Sometimes it’s helpful to begin with the end in mind, so before you dive into the step-by-step process of creating this application, have a quick look at it in action. The following screenshots were captured from a Nexus One running Android 2.2 (Froyo). The images were captured using the Dalvik Debug Monitor Service (DDMS) tool, which installs as part of the Android Developer Tools Eclipse plug-in.

Figure 2 shows the home screen of the application with the sample image loaded. One quick look at the image and you will understand how I wound up as a programmer and not on the set of some television program, thanks to my “fit for radio” face. Please feel free to substitute your own image when building the application yourself.

Figure 2. Home screen of the IBM Photo Phun application

The buttons across the top of the screen allow you to change the image. The first button, Reset, restores the image to this original color image. Selecting the Convert Image button converts the image to grayscale, as shown in Figure 3.

Figure 3. Grayscale image

The Find Edges button starts with the original color image, converts it to grayscale, then performs a Sobel Edge Detection algorithm. Figure 4 shows the results of the edge detection algorithm.

Figure 4. Detecting the edges

Edge-detection algorithms are often used in machine vision applications as a preliminary step in a multi-step image processing operation. From this point, the final two buttons allow you to make the image darker or lighter by changing the brightness of each pixel. Figure 5 shows a brighter version of the grayscale image.

Figure 5. Increased brightness

Figure 6 shows the edges image a bit darker.

Figure 6. Decreased brightness

Now it is your turn.

Creating the application

In this section, we will create the application by leveraging the tools provided in the Eclipse ADT plug-in. Even if you aren’t familiar with creating applications for Android, you should be able to follow along quite readily and learn from this section. The Related links contain helpful articles and tutorials on the basics of creating Android applications.

ADT new project wizard

Creating the application within the Eclipse IDE is very straightforward, thanks to the ADT new project wizard, shown in Figure 7.

Figure 7. Creating a new Android project

When filling out the new project wizard, provide the following information:

1. Valid project name.
2. Build target. Note that for this project, you must use Android V2.2 or Android V2.3 as the target SDK platform level.
3. Valid application name.
4. Package name.
5. Activity name.

Once you have populated the wizard screen, select Finish. Clicking the Next button prompts for creating a “Test” project to accompany this project, which is a useful step, but for another day.

Once the project is populated into Eclipse, you are ready to implement the source files necessary for this application. You will begin with the UI elements of the application.

Android Projects Free Download

Implementing the user interface

The UI for this application is rather straightforward. It contains a single Activity with a handful of Button widgets and an ImageView widget to display the chosen image. Like many Android applications, the UI is defined in the main.xml file, shown in Listing 1.

Listing 1. UI layout file, main.xml

Note the use of two LinearLayout elements. The outer element controls the vertical flow of the UI and the inner LinearLayout is set up for horizontal management of its children. The horizontal layout element holds all of the Button widgets across the top of the screen. The ImageView is set up to center the contained image and has an id attribute, permitting you to manipulate its contents during run time.

The density of the point is 142 PPI and maximum brightness is 404 cd/m2! https://spingol.netlify.app/dell-precision-t5400-windows-7-64-bit-drivers.html. Precision 5520 Mobile Workstation Laptop comes with 15.6-inch IPS panel with a resolution of 1920 1080 pixels of Sharp. Dell Precision 5520 running operating system Windows 10 Pro 64-bit. Intel Core i7 quad processor-6820HQ generation Skylake work with 2.7-3,6GHz frequency, supports threading technologies for parallel processing eight threads. This is probably one of the highest levels found among modern laptop.

Each of the Button widgets has an onClick attribute. The value of this attribute must correspond to a public void method within the containing Activity class, which takes a single View argument. This approach is a quick and easy means of setting up click handlers without the trouble of defining anonymous handlers or getting access to the element during runtime. See Related links for more information on this approach to handling Button presses.

Once the UI has been defined in the layout file, the Activity code must be written to work with the UI. This is implemented in the file IBMPhotoPhun.java, where the Activity class is extended. You can see the code in Listing 2.

Listing 2. IBM Photo Phun imports and class declaration

Let’s break this down into a few notable comments:

1. There are a handful of member variables:

   • tag — This is used in all logging statements to help filter the LogCat during debugging.
   • bitmapOrig — This Bitmap holds the original color image.
   • bitmapGray — This Bitmap holds a grayscale copy of the image and is only used temporarily during the findEdges routine.
   • bitmapWip — This Bitmap holds the grayscale image that is modified when brightness values are modified.
   • ivDisplay — This ImageView is a reference to the ImageView defined in the main.xml layout file.

2. The “NDK Stuff” section includes four lines:

   • The library containing our native code is loaded with a call to System.loadLibrary. Note that this code is contained in a block marked as “static.” This causes the library to be loaded when the application is started.
   • Prototype declaration for convertToGray — This function takes two parameters. The first is a color Bitmap and the second is a Bitmap that is populated with a grayscale version of the first.
   • Prototype declaration for changeBrightness — This function takes two parameters. The first is an integer representing up or down. The second is a Bitmap that is modified on a pixel by pixel basis.
   • Prototype declaration for findEdges. This takes two parameters. The first is a grayscale Bitmap and the second is a Bitmap that receives the “edges only” version of the image.

3. The onCreate method inflates the layout identified by R.layout.main, obtains a reference to the ImageView widget (ivDisplay), then loads the color image from the resources.

   • The BitmapFactory method takes an options parameter that permits you to load the image in the ARGB format. “A” stands for alpha channel and “RGB” stands for red, green, blue, respectively. Many open source image processing libraries expect a 24-bit color image, eight bits each for red, green, and blue, with each pixel consisting of the RGB triplet. Each value ranges from 0 to 255. Images on the Android platform are stored as a 32-bit integer as alpha, red, green, blue.
   • Once the image is loaded, it is displayed in the ImageView.

4. The balance of the methods in this class correspond to “click handlers” for the Button widgets:

   • onResetImage loads the original color image into the ImageView.
   • onConvertToGray creates the target Bitmap as an 8-bit image and calls the convertToGray native function. The resulting image (bitmapWip) is displayed in the ImageView.
   • onFindEdges creates two intermediate Bitmap objects, converts the color image to a grayscale image and calls the findEdges native function. The resulting image (bitmapWip) is displayed in the ImageView.
   • onDimmer and onBrighter each invoke the changeBrightness method to modify the image. The resulting image (bitmapWip) is displayed in the ImageView.

That about wraps up the UI code. It is now time for you to implement the image process routines, but first, we need to create the library itself.

Creating the NDK files

Now that the Android application’s UI and application logic are in place, you need to implement the image processing functions. In order to do this, you need to create a Java-native library with the NDK. In this case, you will use some public domain C code to implement the image processing functions and package them into a library usable by the Android application.

Building the native library

The NDK creates shared libraries and relies on a makefile system. To build the native library for this project, you need to perform the following steps:

1. Create a new folder named jni beneath your project file.
2. Within the jni folder, create a file named Android.mk, which contains the makefile instructions to properly build and name your library.
3. Within the jni folder, create the source file, which is referenced in the Android.mk file. The name of the C source file for this tutorial is ibmphotophun.c.

Listing 3 contains the Android.mk file contents.

Listing 3. Android.mk file

Among other things, this makefile (snippet) instructs the NDK to:

1. Compile the ibmphotophun.c source file into a shared library.
2. Name the shared library. By default, the shared library naming convention is lib.so. So, the resulting file here is named libibmphotophun.so.
3. Specify the required “input” libraries. The shared library relies upon two built-in library files for logging (liblog.so) and jni graphics (libjnigraphics.so). The logging library permits you to add entries to the LogCat, which is helpful during the development phase of your project. The graphics library provides routines for working with Android bitmaps and their image data.

The ibmphotophun.c source file contains a few C include statements and the definition of the argb type, which corresponds to the Color data type in the Android SDK. Listing 4 shows ibmphotophun.c without the image routines, which are presented next.

Listing 4. Ibmphotophun.c macros and includes

The LOGI and LOGE macros make calls to the Logging facility and are equivalent in functionality to Log.i() and Log.e() respectively in the Android SDK. The argb data type defined with the typedef struct keywords allows the C code to access the four data elements of a single pixel stored in a 32-bit integer. The three include statements provide the necessary declarations to the C compiler for jni glue, logging, and bitmap handling, respectively.

It is now time for you to implement some image processing routines, but before we examine the code itself, you need to understand the naming convention of JNI functions.

When Java code calls a native function, it maps the function name to an expanded, or decorated, function, which is exported by the JNI shared library. Here is the convention: Java_fully_qualified_classname_functionname.

For example, the convertToGray function is implemented in the C code as Java_com_msi_ibm_ndk_IBMPhotoPhun_convertToGray.

The first two arguments to the JNI functions include a pointer to the JNI environment and to the calling-class object instance. For more information about JNI, please see the Related links.

Building the library is quite simple. Open a terminal (or DOS) window and change directory to the jni folder where you have stored these files. Make sure that the NDK is in your path and execute the ndk-build script. This script contains all the glue necessary to build the library. The resulting library is placed in the libs folder on the same level as the jni folder (/libs/, for example).

When the Android application is packaged by the ADT plug-in for Eclipse, the library files are included and “wired up” automatically for you. One library file is generated for each supported hardware platform. The correct library is loaded at runtime.

Let’s look at how the image processing algorithms are implemented.

Implementing the image processing algorithms

The image processing routines used by this application were adapted from a variety of public domain and academic routines, along with my own experience as an image processing hobbyist. Two of the functions use pixel operations and the third utilizes a minimal matrix approach. Let’s look first at the convertToGray function in Listing 5.

Listing 5. convertToGray function

This function takes two arguments from the calling Java code: a color Bitmap in the ARGB format and an 8-bit grayscale Bitmap that receives a grayscale version of the color image. Here is a walk-through of the code:

1. The AndroidBitmapInfo structure, defined in bitmap.h, is helpful for learning about a Bitmap object.
2. The AndroidBitmap_getInfo function, found in the jnigraphics library, obtains information about a specific Bitmap object.
3. The next step is to ensure that the bitmaps passed into the convertToGray function are of the expected format.
4. The AndroidBitmap_lockPixels function locks down the image data so you can perform operations directly on the data.
5. The AndroidBitmap_unlockPixels function unlocks previously locked pixel data. These functions should be called as a “lock/unlock pair”.
6. Sandwiched between the lock and unlock functions you see the pixel operations.

Pointer fun

Image processing applications in C typically involve the use of pointers. Pointers are variables that “point” to a memory address. The data type of a variable specifies the type and size of memory you are working with. For example a char represents a signed 8-bit value, so a char pointer (char *) allows you to reference an 8-bit value and perform operations through that pointer. The image data is represented as uint8_t, which means an unsigned 8-bit value, where each byte holds a value ranging from 0 to 255. A collection of three 8-bit unsigned values represents a pixel of image data for a 24-bit image.

Working through an image involves working on the individual rows of data and moving across the columns. The Bitmap structure contains a member known as the stride. The stride represents the width, in bytes, of a row of image data. For example, a 24-bit color plus alpha channel image has 32 bits, or 4 bytes, per pixel. So an image with a width of 320 pixels has a stride of 3204 or 1,280 bytes. An 8-bit grayscale image has 8 bits, or 1 byte, per pixel. A grayscale bitmap with a width of 320 pixels has a stride of 3201 or simply 320 bytes. With this information in mind, let’s look at the image processing algorithm for converting a color image to a grayscale image:

1. When the image data is “locked,” the base address of the image data is referenced by a pointer named pixelscolor for the input color image and pixelsgray for the output grayscale image.

2. Two for-next loops allow you to iterate over the entire image.

   1. First, you iterate over the height of the image, one pass per “row.” Use the infocolor.height value to get the count of the rows.
   2. On each pass through the rows a pointer is set up to the memory location corresponding to the first “column” of image data for the row.
   3. As you iterate over the columns for a particular row, you convert each pixel of color data to a single value representing the grayscale value.
   4. When the complete row is converted you need to advance the pointers to the next row. This is done by jumping forward in memory by the stride value.

For all pixel-oriented image processing operations, you follow the above format. For example, consider the changeBrightness function shown in Listing 6.

Listing 6. changeBrightness function

Free Imei Check Android

This function operates in a manner very similar to the convertToGray function with the following distinctions:

1. This function requires only a single grayscale bitmap. The image passed in is modified in place.
2. The function adds or subtracts a value of 5 from each pixel on each pass. This constant may be changed. I used 5 because it made the image change noticeably with each pass without having to press the plus or minus buttons excessively.
3. The pixel values are constrained between 0 and 255. Be careful when performing these operations with unsigned variables directly as it is easy to “wrap around.” My initial effort on the changeBrightness function resulted in adding 5 to a value such as 252 and winding up with 2. The effect was fun to watch, but not what I was after. That is why I am using the integer named v and casting the pixel data to the signed integer and then comparing that value to 0 and 255.

There remains one more image processing algorithm to examine: the findEdges function, which works a little bit differently from the prior two pixel-oriented functions. Listing 7 shows the findEdges function.

Listing 7. The findEdges function detects outlines within an image

The findEdges routine shares much in common with the prior two functions:

1. Like the convertToGray function, this function takes two bitmap parameters, but in this case, both are grayscale.
2. The bitmaps are interrogated to ensure that they are of the expected format.
3. The bitmap pixels are locked and unlocked appropriately.
4. The algorithm iterates over the source image’s rows and columns.

Unlike the prior two functions, this function compares each pixel to the pixels around it, rather than simply performing a mathematical operation on the pixel value itself. The algorithm implemented in this function is a variant of the Sobel Edge Detection algorithm. In this implementation, I am comparing each pixel to its neighbors with a border of one pixel in each direction. Variants of this and other algorithms may use larger “borders” to obtain different results. Comparing each pixel to its neighbors accentuates the contrast between pixels and in doing so highlights the “edges.”

I am not going to go into the math involved in this algorithm for two reasons. First, it is beyond the scope of this tutorial to care about the math itself. And second, the exact purpose of this tutorial — to (re)use existing C source code — is demonstrated by using an existing image processing algorithm. You are able to obtain the desired results without reinventing the wheel or having to port this code to Java technology. C is an ideal environment for working with image data, thanks to pointer arithmetic.

For more information about image processing algorithms, please see Related links.

Customizing Eclipse

One of the enjoyable aspects of working with the Eclipse IDE is that you rarely have to compile. Anytime you save a file within the Eclipse IDE, your project is built automatically. That is great for the Android SDK (that is, Java) files and the Android XML files, but what about the NDK-built library? Let’s find out.

Extending the Eclipse environment

As mentioned, building the native library is as simple as running the ndk-build command. However, when working with a project for anything other than a trivial exercise, it is a hassle to jump out to a terminal or command window and execute the ndk-build command, return to the Eclipse environment, and force a refresh by “touching” one of the project files, which forces a recompile and repackaging of the complete application. The solution is to extend the Eclipse environment by customizing the build settings for your Android project.

To modify the build settings, first view the properties of the Android project and select Builders in the list. Add a new Builder and move it to the top of the list, as shown in Figure 8.

Figure 8. Modifying the build settings

Each builder has four configuration tabs. Give your builder a name, such as Build NDK Library, then populate the tabs. The first tab (“Main”) specifies the executable tool location and working directory. Point the location to the ndk-build file and the working directory to your jni folder, as shown in Figure 9.

Figure 9. Setting up the Builder properties for the NDK

You only want the ndk-build to operate on this project and not others within your Eclipse workspace, so set this up on the Refresh tab, as shown in Figure 10.

Figure 10. Setting up the Refresh tab

The only time you want the library to rebuild is when either the Android.mk file or the ibmphotophun.c file is modified. To set this up, choose the jni folder under the Specify Resources button on the Build Options tab. Also, specify when you want the build tool to run by checking off the appropriate times, as shown in Figure 10.

Figure 11. Setting up the build options

After clicking OK to confirm your settings, make sure that this NDK build tool is set up as the first entry in the list by selecting the Up button until it is at the top of the list of Builders, as shown in Figure 7.

To test that your Builder is set up properly, open the ibmphotophun.c source file within Eclipse by right-clicking on the source file and choose to open it with the Text Editor. Make a simple change and save the file. You should see the NDK tool-chain output in the console window, as shown in Figure 11. If your C code has errors they are shown in red.

Figure 12. NDK output shows in the console of the Eclipse IDE

With the NDK stitched into your build process, you can focus on writing code and not concern yourself so much with the build environment. Need to make a change to the application logic? No problem, modify the Java code and save the file. Need to tweak the image processing algorithm? No worries, just modify the C routine and save the file. Eclipse and the ADT plug-in takes care of the rest for you.

Summary

This tutorial presented an example of using the Android NDK to incorporate functionality in the C programming language. The functions used here represent a sampling of open source/public domain image processing algorithms. In a similar manner, any valid C code compatible for the Android platform may be utilized with the help of the Android NDK. In addition to the mechanics of using the NDK within Eclipse, you also learned some fundamental concepts around image processing.

Download

os-androidndk-IBMPhotoPhun.source.zip: Source code
